ZQ500 Series Mobile Printers

Extreme environments and bangs and bumps are no match for these lightweight, compact printers. Zebra’s ZQ510™ and ZQ520™ printers are the most rugged printers available. They perform in the widest operating temperature range in the industry and can withstand repeated drops to concrete from up to 6.6 feet. Water spray is no match with their IP54 rating. Featuring Zebra’s Link-OS® environment, these premium printers are easy to integrate, manage and maintain. With large buttons and a user-friendly interface, they are easy to operate, even when wearing gloves.

EXTEND THE FUNCTIONALITY OF YOUR PRINTER

Get more information on
the ZQ500 Series

  • Rugged Design

    The ZQ500 printers are lightweight, yet engineered to handle the bumps, drops and collisions that are part of the job. The printers feature a patented military design that meets third-party-verified MIL-STD 810g military standards for shock, vibration and temperature exposure. The printers can withstand repeated drops to concrete from 6.6’ on multiple sides.

  • environmental endurance

    Zebra not only protects your hardware, but also your operational uptime. The ZQ500 printers meet IP54-rating for resistance to dust and liquids that are common in mobile environments—from dirt in the field to crumbs in a service vehicle. And with cold temperature compensation, the ZQ500 Series automatically optimises and balances print speed and print quality in cold temperatures.

  • Optimised Printing Power

    The ZQ500 printers are Zebra's first products to support a secondary Bluetooth communication channel, an innovative feature that allows one channel to send print jobs to the printer while a second channel performs additional functions such as device management.  The ZQ500 printers also feature "draft mode" which optimises the printing speed (up to 5 inches per minute) for text-only printing.

ZQ510 Mobile Printer

Zebra's Most Rugged Premium Printer for 3" Applications

Optimised for tough environments where a high duty-cycle 3" (72mm) receipt or invoice is needed, and can also print labels for medium-duty-cycle applications.

  • Print Width

    2.83"/72 mm

  • Media Roll outer diameter

    2.0"/51 mm

  • Print Speed

    Up to 5"/127mm per second

  • Weight

    1.39 lbs/0.63 kg with battery

  • Durability

    IP54-rated for dust and liquid protection

    (IP65-rated with the exoskeleton case)

    6.6' (2m) drops to concrete multiple times

    (10' / 3m with the exoskeleton case)

    Tumble-tested

  • Battery Capacity

    PowerPrecision Plus 2450 mAh removable Lithium Ion Smart Battery (7.4V)
    (4900 mAh extended battery optional)

ZQ520 Mobile Printer

Zebra's Most Rugged Premium Printer for 4" Applications

Optimised for tough environments where a high duty-cycle 4" (104mm) receipt or invoice is needed, and can also print labels for medium duty-cycle applications.

  • Print Width

    4.1" / 105mm

  • Media Roll outer diameter

    2.24"/57 mm

  • Print Speed

    Up to 5"/127mm per second

  • weight

    1.73lbs/0.79 kg with battery

  • durability

    IP54-rated for dust and liquid protection (IP65-rated with the exoskeleton case)

    6.6' (2m) drops to concrete multiple times

    (10' / 3m with the exoskeleton case)

    Tumble-tested

  • Battery Capacity

    PowerPrecision Plus 2450 mAh removable Lithium Ion Smart Battery (7.4V)
    (4900 mAh extended battery optional)
