ブリーディングビットのセキュリティ脆弱性

LifeGuardプログラムのロゴ

詳細については、以下を参照してください。

Zebraは、この脆弱性の有効な悪用を認識していません。ただし、影響を受ける2つのZebra製品のソフトウェアを更新して、悪用のリスクを軽減することをお勧めします。追加のLifeGuardの更新は行いません。

Bleeding Bit Logo

BLEEDINGBIT is a security vulnerability that affects Bluetooth® low energy (BLE) chips made by Texas Instruments. It consists of two related remote-control exploit issues:

memory corruption condition (CVE-2018-16986) that can occur during processing of incorrect network traffic from the BLE module. A malicious actor who is close to the target device could execute arbitrary code by sending malformed data, or execute a DoS (denial-of-service) condition which could shut down the device.

An Over-The-Air Download (OAD) functionality issue (CVE-2018-7080) that can be triggered only when the relevant BLE radio function is enabled by the device owners (it is disabled by default). A malicious actor could push altered copies of these images to gain control of the device.

影響を受ける製品

Only the following two BLE badge products are affected. Zebra mobile devices, handheld devices, barcode scanners and printers are not impacted.


Zebra製品 SKU説明利用可能な更新
GE-MB6000-01-WRモバイルBLEバッジ 1月、2019日
GE-MB5000-01-WR固定のBLEバッジ1月、2019日

Only the above Zebra devices are impacted by CVE-2018-16986 only and CVE-2018-7080 does not apply since the OAD feature in the Texas Instruments’ (TI) CC2640 BLE chip is disabled.  The Zebra devices have an STMicroelectronics Microcontroller Unit (MCU) and BLE chip CC2640.  The MCU firmware is written on CYPRESS WICED SDK.  The firmware of the TI CC2640 is based on TI’s BLE SDK 2.1. The MCU connects to the CC2640 via a UART port. The MCU sends BLE HCI commands to the CC2640, the CC2640 does the BLE scanning continuously, and the CC2640 returns the scanned BLE packets in a predefined format to MCU.

During the scanning process, there is possible memory corruption in the CC2640 per CVE-2018-16986.  If the CC2640 is exploited, it may send garbage data over the UART port to the MCU. The MCU may or may not discard the data, depending on the data itself.  In this manner, the badge could become useless as there is no valid BLE packet data to collect inside the MCU.

If an attacker wants to gain full control of the device the attacker needs to first gain control of the MCU. The attacker would need to find an enabling vulnerability in WICED SDK and the STM MCU as well. The hacker would then need to attack the MCU through the exploited CC2640 chip via the UART port. The possibility of exploiting the MCU (achieved in conjunction with the exploitation of undiscovered vulnerabilities in both the Wicked SDK and the STM MCU) to gain full control over the device is relatively low.

To avoid the potential of this vulnerability, Zebra must port the CC2640 firmware code to the TI BLE SDK 2.2.2. For new device this updated CC2640 firmware code can be used. For deployed devices the updated CC2640 firmware can be updated over-the-air through the MCU where the MCU pushes the new firmware to CC2640 via UART port.

免責事項: Zebraは、Googleがそれぞれのセキュリティ情報をリリースする時期について、セキュリティアップデートをリリースするようあらゆる試みを行っています。ただし、セキュリティ更新プログラムの配信時間は、地域、製品モデル、およびサード パーティ製ソフトウェアの供給業者によって異なる場合があります。状況によっては、セキュリティ更新プログラムをインストールする前に、OSを最新のメンテナンスリリースに更新する必要があります。個々の製品の更新プログラムは、具体的なガイダンスを提供します。

特に明記されていない限り、これらの新たに報告された問題から積極的な顧客の搾取や悪用の報告はありません。



Zebraテクノロジーズ製品の潜在的なセキュリティ上の問題を認識していますか?
